Port-A-Cool Evaporative Cooling

48″ UNIT SPECIFICATIONS


Two Speed
Air Delivery CFM
11,000/17,000
Fan motor
1 hp / 115v / 8.7 amp
Pump
1/6 hp/ 115v/5 amp
Water reservoir
25 gallons
Dimensions
86″h x 74″w x 36″d
Unit weight
345 lbs.
Shipping weight
415 lbs.
Box Size
88″h x 75″w x 37″d
Cooling Capacity
3,500 sq. ft.

Extras for 48″

Replacement Pads
PAD6060/G
Vinyl Cover
PAC-CVR-03
Port-A-Filler Tank
PAC-ACC-0 I
(See “Accessories” page
for details on these items)

48" belt-drive Two speed Port-A-Cool



48″ Hazardous Location
Stock # PAC2K48EP

Air Delivery CFM
17,500
Fan motor
1 hp / 110/220v / 13.8 amps
Pump
1/4 hp / 110/220v / 4.2 amps
Water reservoir
25 gallons
Dimensions
86″h x 74″w x 36″d
Unit weight
400 lbs.
Shipping weight
475 lbs.
Box Size
88″h x 75″w x 37″d
Cooling Capacity
3,500 sq. ft.
48" Hazaardous Location Port-A-Cool



24″ HP UNIT SPECIFICATIONS

Air Delivery CFM
6,700
Fan motor
1/3 hp/ 115v / 4.5 amp
Pump
1/6 hp/ 1 15v / 5 amp
Water reservoir
14 gallons
Dimensions
53″h x 50″w x 25″d
Unit weight
155 lbs.
Shipping weight
180 lbs.
Box Size
55″h x 50″w x 26″d
Cooling Capacity
1,800 sq. ft.

Extras for 24″
Replacement Pads
PAD6036/G
Vinyl Cover
PAC-CVR-O I
Port-A-Filler Tank
PAC-ACC-O I
(See “Accessories” page

for details on these items)

24" Fan Diameter Direct Drive Variable Speed Port-A-Cool



24″Air Mover Hazard Location
Stock # PAC2K24AD
Pneumatic Model

Air requirements
164 SCFM @ 40 PSIG
Fan
4,898 CFM
Support frame
Aluminum
Water reservoir
14 gallons
Evaporative media
36″h x 12″w x 6″d
Dimensions
73″h x 49″w x 72″d
Box Size
92″h x 75″w x 37″d
Unit Weight
128 lbs.
Shipping Weight
188 lbs.



24" Air Mover Hazard Location Port-A-Cool



16″ FILLER CART SPECIFICATIONS
Three Speed

Air Delivery CFM
2,500 / 3,280 / 3,900
Fan motor
1/2hp / 110v / 3.4 amp
Pump
110v / 60hz / 1.7 amp submersible
Water reservoir
22 gallons
Dimensions
59″h x 37.5w x 22″d
Unit weight
115 lbs.
Shipping weight
145 lbs.
Box Size
60″h x 39″w x 24″d
Cooling Capacity
900 sq. ft.
Support Frame
Welded Steel w/casters

Extras for 16″

Replacement Pads
PAD6024/G

Vinyl Cover
PAC-CVR-02

Cart for 16″ Units
PAC-ACC-30
(For PAC2K163S & PAC2K163SHD) Unit not included

Port-a-Cool 16" Filler Cart



16″ HD UNIT SPECIFICATIONS
Three Speed

Air Delivery CFM
2,500 / 3,280 / 3,900
Fan motor
1/2hp / 110v / 3.4 amp
Pump
1/70hp / 115v / 0.92 amp
Water reservoir
2 gallons
Dimensions
30.5″h x 37.5″w x 22″d
Unit weight
70 lbs.
Shipping weight
80 lbs.
Box Size
31.5″h x 38″w x 23″d
Cooling Capacity
900 sq. ft.
16" HD Direct Drive Three Speed Port-a-Cool



16″ UNIT SPECIFICATIONS
Three Speed

Air Delivery CFM
1,540 / 1,930 / 2,230
Fan motor
1/2hp / 110v / 3.4 amp
Pump
1/70hp / 115v / 0.92 amp
Water reservoir
3 gallons
Dimensions
30.5″h x 37.5″w x 22″d
Unit weight
64 lbs.
Shipping weight
74 lbs.
Box Size
31.5″h x 38″w x 23″d
Cooling Capacity
600 sq. ft.
16" Direct Drive Three Speed Port-a-Cool



16″ Air Mover
Hazard Location

Stock # PAC2K 16AD
Pneumatic Model

Air requirements
73 SCFM @ 40 PSIG
Fan
2,200 CFM
Support frame
Aluminum
Water reservoir
3 gallons
Evaporative media
24″h x 12″w x 6″d
Dimensions
58″h x 39″w x 65″d
Box Size
65″h x 64″w x 33″d
Unit Weight
93 lbs.
Shipping Weight
145 lbs.
16" Air Mover Hazard Location Port-a-Cool



Adapter for Ducting
(16″ electric units only)

Stock # PAC-ADP- 16

SEE ACCESSORIES PAGE FOR DETAILS
FOR PAC2KI63S• PAC2KI63SHD
PAC2KI63SFC (Ducting not included)

Adapter for ducting for 16" electric Port-A-Cool



36″ UNIT SPECIFICATIONS

Three speed

Air Delivery CFM
4,800 / 6,600 / 9,600
Fan motor
1/2hp / 115v / 6.5 amp
Pump
1/6hp / 115v / 5 amp
Water reservoir
20 gallons
Dimensions
67″h x 62″w x 32″d
Unit weight
205 lbs.
Shipping weight
245 lbs.
Box Size
68″h x 64″w x 33″d
Cooling Capacity
2,500 sq. ft.

Single Speed

Air Delivery CFM
9,600
Fan motor
1/2hp / 115v / 7.4 amp
Pump
1/6hp / 115v / 5 amp
Water reservoir
20 gallons
Dimensions
67″h x 62″w x 32″d
Unit weight
195 lbs.
Shipping weight
235 lbs.
Box Size
68″h x 64″w x 33″d
Cooling Capacity
2,500 sq. ft.

HP Unit

Air Delivery CFM
10,100
Fan motor
1/2hp / 115v / 6.3 amp
Pump
1/6hp / 115v / 5 amp
Water reservoir
20 gallons
Dimensions
67″h x 62″w x 32″d
Unit weight
205 lbs.
Shipping weight
245 lbs.
Box Size
68″h x 64″w x 33″d
Cooling Capacity
2,500 sq. ft.

36″ HP Unit PAC2K36HPVS (shown right)
36″ UNIT ALSO AVAILABLE IN:
Three Speed …………….Stock# PAC2K363S
Single Speed ……………Stock# PAC2K36IS

Extras for 36″

Replacement Pads
PAD6048/G
Port-A-Filler Tank
PAC-ACC-01
Vinyl Cover
PAC-CVR-01
Pneumatic Cast Kit
CASTER-KIT-02
36" HP Port-A-Cool



36″ Reaction Fan Hazard Location
Stock # PAC2K36AD
Pneumatic Model

Air requirements
196 SCFM @ 80 PSIG
Fan
9,100 CFM
Support frame
Welded Steel
Water reservoir
20 gallons
Evaporative media
48″h x 12″w x 6″d
Dimensions
65″h x 63″w x 43″d
Box Size
78″h x 73″w x 48″d
Unit Weight
352 lbs.
Shipping Weight
460 lbs.
36" Reaction Fan Hazard Location Port-A-Cool



36″ Hazardous Location
Stock # PAC2K36EP

Air Delivery CFM
9,600
Fan motor
1/2hp / 110/220v / 9.2 amps
Pump
1/4hp / 110/220v / 4.2 amps
Water reservoir
20 gallons
Dimensions
67″h x 62″w x 32″d
Unit weight
300 lbs.
Shipping weight
330 lbs.
Box Size
68″h x 64″w x 33″d
Cooling Capacity
2,500 sq. ft.
36" Hazardous Location Port-A-Cool



EMERGENCY SERVICES COOLING UNIT

A self-contained cooling solution
for emergency situations

Each E.S.C.U. Trailer is equipped with …

  • Port-A-Cool® Portable Evaporative Cooling Unit(s)
  • 50-gallon Water Tank
  • 120v / 240v Generator
  • Locking Toolbox
  • Trailers available in other models and colors

E.S.C.U. SINGLE 36″ (PAC-MOB-01)
Weight 1280 lbs.
Dimensions 80″h x 72″w x I62″d

Emergency Services Cooling Unit
